LocationCaspian Sea
TypeSubsea pipelines
Scope of workEPIC
Year2016
Main parameters:
Sea depth:23-34 m
Type of insulation:3LPE
Number of piles:32 nos.
Design pressure:5 MPa
Pipelines diameter х thickness:457,2 mm х 12,7 mm (18” LAM-B – BLOCK-1)508 mm х 12,7 mm (20” BLOCK-1 – BLOCK-2)355,6 mm х 12,7 mm (14” LAM-C – LAM-B)323,9 mm х 12,7 mm (12” BLOCK-4 – точка врезки)273,1 mm х 15,9 mm (10” ZHD-A – BLOCK-4)168,3 mm х 15,9 mm (6” ZHD-25 – точка врезки)
Product:Oil product
